ZH-WPII320R-Y260*
Product Features
Power：320W
Series：CC LED Driver
Application：Tunnel light
Certificate： FCC, CRUUS
Warranty：5 years
Product Description
CC LED Driver
Features
Parameters
Reference
Efficiency up to 95%
Dimming: 277-480Vac, PWM, Resistor
Dim-to-Off
Surge protection: CM: 6KV, DM: 6KV
Auxiliary Power: 12V/0.3A
Standby Power<0.5W
IP54
TYPE HL, suitable for hazardous locations
Protections: SCP/OTP/OPP
Warranty: 5 years
| Reted Input Voltage High Voltage |
| Max. Pout 320 W |
| Dimension φ225*52.5*35（mm） |
Model | Full Power | Vout Range(Vdc) | Output Current(A) | Max.Pout(W) | PF(Typ.) | Eff.(Typ.) | SIZE(L×W)(mm) | Surge protection |
| ZH-WPII320R-Y260* | 320 | 180-260 | 1.0-1.6 | 320 | 0.95 | 0.95 | 225×52.5×35 | 6KV/6KV |
